Electric
Output Signal	SPDT output
Electrıcal Constructıon	NO/NC
Electrical Connector Type	DIN 43650-A M12 x 1 (4 pin)
Max. Supply Voltage	250 VAC
Current	5A (Max. VAC)
Connection Principle	3 Wire

Pressure
Type of Pressure	Relative Pressure
Min. Signal Pressure	0,2 bar 2,9 psi 20 kPA 0,02 Mpa
Max. Signal Pressure	600 bar 8700 psi 60000 kPa 60 Mpa
Bursting Pressure	40-750 bar 580-8700 psi 4000-60000 kPa 4-60 Mpa
Pressure Indicator	Yok

Temperature
Min. Temperature	- 20 °C 20 °F
Max. Temperature	+100 °C 212 °F

Materiel
Mechanical Connection	Bottom Flange Connection G1/4
Body	Aluminum Body (6013 AL) Stainless Body (316L)
Sealing Element	NBR
