Electric
Output Signal	Analog
Electrıcal Constructıon	4…20 mA0...10 V
Electrical Connector Type	DIN 43650-ADIN 43650-CM12 x 1 (4 pin)
Max. Supply Voltage	30 VDC
Min. Supply Voltage	8 VDC 14 VDC
Connection Principle	2 Wire 3 Wire

Pressure
Bursting Pressure	1050 bar15225 psi105000 kPa105 Mpa
Pressure Indicator	Yok
Type of Pressure	Relative pressure Vacuum
Min. Signal Pressure	-0,85 bar
Max. Signal Pressure	600 bar 8700 psi 60000 kPa 60 Mpa

Temperature
Min. Temperature	-20 °C 20 °F
Max. Temperature	85 °C 185 °F

Materiel
Mechanical Connection	G1/2"-G1/4”- G1/8” 1/4”BSPT - 1/8”BSPT M10x1,0 - M12x1,5 1/8”NPT - 1/4”NPT
Body	Stainless (316L)
Sealing Element	NBR
